Apply ANSI/ESD S20.20 in PCBA Assembly System and Mfg Effectively (ESD 351)

Apply ANSI/ESD S20.20 in PCBA Assembly System and Mfg Effectively (ESD 351)


This course will equip the learner with the skills to apply ESD TR53 compliance verification within an electrostatic discharge protected area (EPA) with ESD sensitive devices (ESDS), inclusive of PCBA assembly and systems. The learner will be introduced to ANSI/ESD S20.20-2014 product qualification vs compliance verification within an EPA to protect ESDS & PCBA. This course prepares the learner to apply techniques of compliance verification for EPA control items, instruments & setup, interpret measurement readings and troubleshooting, as per ESD TR53.


Learning Outcome:


In the course, the learner will

1) Understand and apply ANSI / ESD S20.20-2014 and ESD TR53 for electrostatic discharge sensitive printed circuit board (PCBA) assembly systems and manufacturing. 理解和实际使用ANSI / ESD S20.20-2014和ESD TR53, 用于生产车间的静电放电敏感印刷电路板(PCBA)装配系统和制造。

2) Distinguish ANSI / ESD S20.20-2014 product qualification and compliance verification, and considering the degradation of the ESD materials. 区分 ANSI / ESD S20.20-2014产品认证和符合性验证,并考虑到ESD材料的退化。

3) Apply ESD TR53 compliance verification within EPA. 在工厂执行ESD TR53符合性验证。


Target Participants:


This is a 2-day course targeted at personnel who works within EPA to apply and troubleshoot compliance verification of technical elements, which protect ESDS, PCBA assembly and systems. It is also targeted at managers and engineers who perform ESD TR53 Compliance Verification, as per ANSI/ESD S20.20 ESD Control Program.


**10 Pax to start the class**
